ACLT-35 Programmable AC Load
Engineered for AC charging pile validation, the ACLT-35 Programmable AC Load features single-phase 7.875kW and three-phase 23.625kW load testing. With a 35A max capacity, 5A tuning steps, and L1/L2/L3 fast interfaces, this compact, castored load box ensures effortless, single-person on-site operation.
Metrology-Grade 16A/32A AC EVCS Load Simulation for Rapid Field Audits
Scalable Multi-Unit Parallel Architecture with 5A High-Resolution Tuning
RS485 Telemetry Control Network Backed by 39-Year GENY Mastery
basic param
- Small size and light weight, with casters and convenient for on-site handling and transportation.
- Multiple units can be paralleled to meet the on-site testing requirements of AC charging piles.
- The load has the AC charging pile load simulation function, which can meet the load test requirements of AC charging piles with different loading currents.
- The load loading mode is constant current loading, which can meet the load test requirements for 16A and 32A AC charging piles.
- Load nominal voltage: 225V/50Hz, single-phase power 7.875kW, three-phase can achieve maximum 23.625kW load test.
- The load is equipped with quick interfaces for L1, L2, L3 three-phase, with dedicated power cables for quick on-site wiring.
- Load control Settings: a total of 4 Settings: 5A, 10A, 10A, 10A, current combined: 35A, minimum adjustment step 5A.
- The loading switch and gear button are respectively equipped with a loading indicator light and a gear indicator light, indicating the loading status clearly.
- The device is equipped with an RS485 communication interface for remote communication control via software.
- Casters are added to the bottom of the load for easy movement.
- The control mode is manual and remote.
